Creative, compact & powerful cinematic lighting

Unleash your creative vision and bring high-quality cinematic lighting to your set with the compact and lightweight Gemini 1×1 Soft. Delivering the most lighting options ever seen in a 1×1 fixture, control light precisely from a beautiful soft white light to full saturated RGBWW control in an instant; Gemini delivers the ultimate flexibility you need for endless creative lighting options all in one unique fixture. Whether in the studio or out on location, the user-friendly quick-to-rig Gemini 1×1 could be the only panel you’ll ever need.

Learn more about Gemini 1x1 Soft

Technical Specifications

Range 1x1 LED Panels 1x1 LED Panels
Color Temperature RGBWW RGBWW
Max Beam Angle 95 95
Comparative Output 614 lux Daylight at 10ft/3m, 557 Tungsten at 10ft/3m 614 lux Daylight at 10ft/3m, 557 Tungsten at 10ft/3m
CRI Daylight 97 97
CRI Tungsten 94 94
Width 32 cm 12.6 in
Height 32 cm 12.6 in
Depth 11.8 cm 4.65 in
Weight 5.3 kg 11.7 lb
Gel Filter Optional Daylight or Tungsten source Optional Daylight or Tungsten source
Max Power Draw 200W 200W
Optics Medium diffusion panel Medium diffusion panel
Remote Control Built-in Wired DMX (RJ-45 and XLR5) / Wireless DMX (LumenRadio) Module / Bluetooth Module Built-in Wired DMX (RJ-45 and XLR5) / Wireless DMX (LumenRadio) Module / Bluetooth Module
IP Rating IP20 IP20
Field Angle 157 157

In The Box

  • Litepanels Gemini 1×1 Soft RGBWW LED Panel
  • Standard Yoke
  • Medium Diffuser
  • UK Power Cable
  • Limited one-year warranty, extend to a total of two years with product registration
