Gemini 2×1 Soft


Cinematic soft lighting

Unleash your creative vision and bring high quality cinematic lighting to your set with the versatile Gemini 2×1 Soft. Control light precisely with a wide range of options, from a beautiful soft white light to full RGBWW, Gemini delivers the instant flexibility you need for creative lighting. Whether in the studio or out on location, the lightweight quick-to-rig Gemini 2×1 Soft provides exceptional results for any production.

Gemini 2X1 Soft on Cine

Cine quality, accurate white light for life in true color

True to life color reproduction comes naturally with Gemini. Consistently accurate and dependable white light with no color shift at any intensity from 100-0.1% means everything on set appears true to life and the skin tones of your on-screen talent are rendered perfectly.

Full RGB control for endless creativity

One light, infinite creativity. With precision control over 16.7 million colors and a wide range of gels and fully customizable cinematic effects, Gemini is the only fixture you will need on set. From simulating fire or a television, washing a green screen or matching a color palette, Gemini’s beautifully rich color output with outstanding depth, vibrancy and intensity means that whatever the situation the light you need is already on set and just the touch of a button away.

Gemini 2X1 Full RGB

Flicker free output at any level

Fixing flicker in post is a thing of the past with Gemini. With advanced LED control to create seriously stable and flicker free light at any shutter angle, frame rate or at any intensity level from 100 – 0.1% you can spend more time shooting and less time in the edit suite.

Lightweight and agile for rapid rigging

Ready to work right out of the box with no assembly required, Gemini 2×1 Soft is ready to start work immediately. Weighing in at just 22.27lbs (10.1kg) including the built-in power supply Gemini 2×1 Soft is easy to transport or move around your set, perfectly balanced and positioned quickly for action.

Gemini 2X1 Hard on set
Gemini LED Panel UI

Simple to use

With an intuitive UI for fast menu selection and customizable pre-set buttons for quick recall of your favorite scenes and settings, Gemini makes professional results available at the touch of a button, helping you open.

Take Control

Take creative control of Gemini 2×1 Soft in the studio or on location with the intuitive on-board control panel. For remote control choose from wired DMX or go wireless with WiFi and Bluetooth options as well as Litepanels smart iOS apps for a galaxy of light, effects and color at your fingertips.

Gemini 1X1 power inputs
Gemini 2X1 with battery

Battery power for cine lighting anywhere

For maximum flexibility to take your cine quality lighting anywhere, Gemini 2×1 Soft can be powered at full intensity for over an hour with batteries such as the Anton/Bauer DIONIC 26V as well as other 13-28V DC batteries with optional V-Mount or Gold-Mount battery plates to place your lighting anywhere your creativity takes you.

Built stronger for a longer life

Tough enough to handle life on the road, Gemini is manufactured to industrial standards using durable, robust materials. Designed to protect your investment, you can rely on the Gemini 2×1 Soft to work first time, every time for years to come.

Gemini 2X1 Hard

Gemini 2×1 Soft RGBWW LED Panel


  • Front area dimension: 23.75” x 11”
  • 93º Beam angle, 156º Field angle
  • Lux at 10ft/3m: 1079 (Daylight), 906 (Tungsten)
  • Color temperature range 2,700-10,000K
  • Outstanding color accuracy, CRI: 99, TLCI: 99
  • Wired or wireless DMX & Bluetooth remote control options
  • Multi-voltage 100-240VAC; DC Input 13-28VDC
  • Weight: 22.27lbs (10.1kg)

A choice of lighting profiles make Gemini the most versatile way to perfectly light the scene.



Allows individual control over the red, green, blue and white LEDs to generate over 16.7 million beautifully rich colors.



Offers highly accurate correlated color temperature control across the full spectrum from a warm 2700K to a cool 10000K with full plus minus green/magenta fine tuning.



For precision color mixing using hue, saturation and intensity to deliver any color in the 360º color wheel.



Features a digital library of 300 industry-standard gels that can be used over daylight or tungsten base white light to create hundreds more color options.



Delivers 11 fully-customizable cinematic special effects including:


XY Mode

Uses XY coordinates within the CIE color space to simplify the process of accurately matching other light sources.

Gemini Effects List

Create, shape and modify

Creativity is unbound with the wide range of Gemini accessories delivering multiple ways to shape and modify light.  Softboxes, grids, barndoors and more fit simply and quickly to Gemini fixtures for endless lighting control options.
