Gemini 1×1 Soft

RGBWW LED Panel

Compact cinematic soft lighting

Unleash your creative vision and bring high-quality cinematic lighting to your set with the compact and lightweight Gemini 1×1 Soft. Control light precisely from a beautiful soft white light to full saturated RGBWW control in an instant; Gemini delivers the ultimate flexibility you need for endless creative lighting options. Whether in the studio or out on location, the user-friendly quick-to-rig Gemini 1×1 could be the only panel you’ll ever need.

Gemini 1X1 soft LED panel being used on Set

Cine quality, accurate white light for life in true color

True to life color reproduction comes naturally with Gemini. Consistently accurate and dependable white light with no color shift at any intensity from 100-0.1% means everything on set appears true to life and the skin tones of your on-screen talent are rendered perfectly.

Full RGB control for endless creativity

One light, infinite creativity. With precision control over 16.7 million colors and a wide range of gels and fully customizable cinematic effects, Gemini is the only fixture you will need on set. From simulating fire or a television, washing a green screen or matching a color palette, Gemini’s beautifully rich color output with outstanding depth, vibrancy and intensity means that whatever the situation the light you need is already on set and just the touch of a button away.

Gemini 1X1 Soft LED Panel being used to light bar scene

Flicker free output at any level

Fixing flicker in post is a thing of the past with Gemini. With advanced LED control to create exceptionally stable and flicker free light at any shutter angle, frame rate or at any intensity level from 100 – 0.1% you can spend more time shooting and less time in the edit suite.

Lightweight and agile for rapid rigging

Ready to work right out of the box with no assembly required, Gemini is ready to start work immediately. Weighing in at just 5.3kg Gemini is easy to transport and quick to rig or move around your set, use lightweight lighting supports or even hand hold for ultimate lighting versatility. The adjustable onboard power supply mount means that Gemini can be perfectly balanced and positioned quickly to be ready for action.

Gemini 1X1 soft panel on product shoot
Gemini LED Panel UI

Simple to use

With an intuitive UI for fast menu selection and customizable pre-set buttons for quick recall of your favorite scenes and settings, Gemini makes professional results available at the touch of a button, helping you operate with efficiency and save time on set.

Take Control

Take creative control of Gemini in the studio or on location with the intuitive on-board control panel. For remote control choose from wired RJ45 and XLR5 DMX options or go wireless with WiFi and Bluetooth options as well as Litepanels smart iOS apps for a galaxy of light, effects and color at your fingertips.

Gemini 1X1 power inputs
Gemini 1X1 Soft being powered by Dionic XT

Battery power for cine lighting anywhere

For maximum flexibility to take cine quality lighting anywhere, Gemini can be powered at full intensity for over two hours with batteries such as the Anton/Bauer DIONIC 26V. Quickly mount 13-28V DC batteries with optional V-Mount or Gold-Mount battery plates to place your lighting anywhere your creativity takes you.

Built stronger for a longer life

Tough enough to handle life on the road, Gemini is manufactured to industrial standards using durable, robust materials. Designed to protect your investment, you can rely on the Gemini 1×1 Soft to work first time, every time for years to come.

Gemini 1x1 Soft LED Panel

Gemini 1×1 Soft RGBWW LED Panel

GEMINI SPECS

  • Front area dimension: 12.6”x12.6”
  • 95º Beam angle, 157º Field angle
  • Lux at 10ft/3m: 614 (Daylight), 557 (Tungsten)
  • Color temperature range 2,700-10,000K
  • Outstanding color accuracy, CRI: 97, TLCI: 94
  • Wired or wireless DMX & Bluetooth remote control options
  • Multi-voltage 100-240VAC; DC Input 13-28VDC
  • Weight: 12lbs (5.3kg)

A choice of lighting profiles make Gemini the most versatile way to perfectly light the scene.

RGBW

RGBW

Allows individual control over the red, green, blue and white LEDs to generate over 16.7 million beautifully rich colors.

CCT

CCT

Offers highly accurate correlated color temperature control across the full spectrum from a warm 2700K to a cool 10000K with full plus minus green/magenta fine tuning.

HSI

HSI

For precision color mixing using hue, saturation and intensity to deliver any color in the 360º color wheel.

GEL

GEL

Features a digital library of 300 industry-standard gels that can be used over daylight or tungsten base white light to create hundreds more color options.

Effects

Effects

Delivers 11 fully-customizable cinematic special effects including:

XY

XY Mode

Uses XY coordinates within the CIE color space to simplify the process of accurately matching other light sources.

Gemini Effects List

Create, shape and modify

Creativity is unbound with the wide range of Gemini accessories delivering multiple ways to shape and modify light.  Softboxes, grids, barndoors and more fit simply and quickly to Gemini fixtures for endless lighting control options.
